IP Camera WiFi Camera PTZ dome outdoor Motion auto Tracking 4X Digital Zoom Two Way Talk 1080P Full Color Night Vision Camhipro

$34.57$58.63

Brand Name: BOAVISION
Type: IP Camera
Supported Operating Systems: windows 10
Supported Operating Systems: Windows 7
Supported Operating Systems: windows xp
High Definition: 2.0 Megapixels
Lens (mm): 3.6mm
Style: Dome Camera
Certification: CE
Connectivity: IP/Network Wireless
Origin: CN(Origin)
Installation: Side
Wall Bracket: Side
Power Consumption(W): Day: 3W; Night: 12
Color: White
Minimum Illumination(Lux): 0.05 Lux /0 Lux(IR on)
Sensor: CMOS
Megapixels: 2MP
Sensor Brand: SONY
Special Features: Waterproof / Weatherproof
Storage: None
Alarm Action: Local Alarm
Video Compression Format: H.264
Video Compression Format: H.265
Power Supply: Normal
TF Card: None
IR Distance(m): IR 30m
is_customized: Yes
Power Supply(V): 12V 2A
Model Number: HX-HD22M102M & HX-HD22M102M
Viewing Angle : 75°
Technology: Infrared
Dimensions (L x W x D)(mm): 165*150*90mm
Supported Mobile Systems: ios
Supported Mobile Systems: Android
Network Interface: RJ-45 10/100Mb Ethernet Slot
Audio Output: Built-in Loud Speaker
Item Name: 2.5 Inch Super Mini PTZ Dome WIFI IP Camera
Resolution: HD 1080P
Fixed Lens: 3.6mm Fixed Lens
LEDs: 6Pcs White light/4Pcs IR LEDs
Wireless Protocols: 802.11b/g/n, 150Mbps, 10-50m
Two Way Audio: Support Talk Back(With Speaker)
Microphone Range 15m: Loudspeaker Range 60m
Pan Tilt Rotation: Horizontal:355 Degree & Vertical:90 Degree
Housing Material: ABS Plastic,Waterproof IP65
1 TF card slot: Up to 128G(Don’t included TF Card)
Support iPhone,Android APP: CamHipro/Camhi

1080P 12V 2A Power
1080P 12V 2A Power
1080P 16GB 2A Power
1080P 16GB 2A Power
1080P 32GB 2A Power
1080P 32GB 2A Power
1080P 64GB 2A Power
1080P 64GB 2A Power
1080P No Power
1080P No Power
China
China
Russian Federation
Russian Federation
SPAIN
SPAIN
United States
United States
AU Plug
AU Plug
EU Plug
EU Plug
UK Plug
UK Plug
US Plug
US Plug
3.6mm
3.6mm
Clear

Description

IP Camera WiFi Camera PTZ dome auto Tracking 2.4ghz Two Way Talk Motion Detection 1080P pan Tile Full Color Night Vision Camhipro/Camhi

HD 1080P 2 Inch WIFI PTZ IP Camera

CCTV Security IP Camera Onvif Outdoor IR 30M Two Way Audio P2P CamHipro/CamHi

Motion-Tracking&Alerts

Motion-Tracking allows the camera to track objects in motion. When enabled the camera will begin to automatically record and follow the object in motion.

4X Digital Zoom(CamHipro)

Anytime, Anywhere To See Where You Want To See

Useage Scenarios

Can Be Used In A Variety Of Environments, Whether It Is Rain Or Dust Can Be Effectively Isolated

Two Way Audio Talk Back

Built-In Microphone, Support Two Way Audio Talk Back ( With Speaker )

Support P2P

Provide Android & IOS APP (CamHipro) And Professional CMS PC Client Software

Waterproof IP65

ABS Plastic Housing Material, Outdoor Use, Waterproof IP65

Day And Night Color Vision

6Pcs Spot White light LED+4 Array IR LEDs, 30m B/W Night Vision,20M Color Night vision

Pan Tilt Rotation

Horizontal: 355 Degree & Vertical: 90 Degree

Support TF / Micro SD Card

Up To 128GB, Very Easy To Install The TF / Micro SD Card ( Don’t Included TF Card)

Motion Detection & Alarm Linkage

Can Set 4 Independent Detection Region (1-100 Sensitivity Can Be Set) Alarm Send Pictures To The Specified Mailbox, Alarm Upload Pictures And Videos To The FTP Server, Alarm Write Pictures And Videos To Micro SD Card, Alarm Message Push

2 Inch Super Mini Size

3.6mm Fixed Lens ( No Support Zoom)

Packing List

Specification selection

Features :

2 Inch Auto Tracking Super Mini Size PTZ Dome WIFI IP Camera

3.6mm Fixed Lens(4X Digital zoom )

Support HD 1080P High Quality Resolution

Support TF/Micro SD Card, up to 128G  (TF Card Optional Choose)

Pan Tilt Rotation, Horizontal:355° & Vertical:90°Ø

6pcs Spotlight LED+4Pcs Array Infrared LEDs , 30m B/W Night Vision/20M Color Night vision

Support P2P, View & Anywhere & Anytime

Provide Android & IOS APP (CamHi) and professional CMS PC client software

Wireless Protocols : 802.11b/g/n, 150Mbps, 10-50m

ABS Plastic Housing Material,Outdoor Use,Waterproof IP65

Built-in Microphone,Loud Speaker,Support Two Way Audio Talk Back

Microphone Effective Range 15 MetersLoud Speaker Effective Range 60 Meters

The SD Card Slot Is Designed On The Camera’s Back Cover

Very Easy to Install the TF/Micro SD Card .  (TF Card Optional Choose)



Specifications:

Model HX-HD22M102M
Camera Operating system Embedded Linux OS
Megapixel 1920*1080
Lens interface type M12
Lens 3.6mm Fixed Lens(4X Digital zoom )
View angle 75deg
Min.illumination 0.05 Lux  / 0 Lux(IR on)
Day&Night mode Auto IR-CUT
Night vision distance 6pcs Spotlight LED(20M)+4Pcs Array Infrared LEDs(30M)
Video

Video compression

standard

H.264 Main Profile/H.264 Baseline
Video streaming Dual streaming
Video resolution First stream: 1080P(1920×1080), 720P(1280×720)
Second stream: Q720P(640×480/640×352), QQ720P(320×240/320×176)

JPEG stream :(Monitoring for mobile phones),

Q720P(640×352), QQ720P(320×176)

Video code rate 32 to 8192Kbps. supports constant bitrate/variable bitrate
Video frame rate 12fps(PAL 50HZ). 12fps(NTSC 60HZ)
Image settings Brightness,saturation,contrast,Sharpness,Exposure,flip,mirror
Image enhancement

Backlight compensation,Automatic white balance,Digital WDR,

3D digital noise reduction

Audio

Audio compression

standard

G.726/G.711
Audio code rate Rate adaptive
Audio Input Support, Built-in Microphone
Audio Output Support Two Way Audio Talk , Built-in Loud Speaker
Function Motion detecting Can set 4 independent detection region (1-100 sensitivity can be set)
Alarm linkage

Alarm send pictures to the specified mailbox,

alarm upload pictures and videos to the FTP server,

alarm write pictures and videos to Micro SD card, alarm message push

Privacy mask Maximum support 4 users to simultaneously browse
OSD Support camera name, date and time information superimposed
User management Supports user and rights management
Simultaneous viewers

maximum support 12 users to simultaneously

browse (each stream supports 4 users)

Network protocol

TCP/IP,HTTP,TCP,ICMP,UDP,ARP,IGMP,SMTP,

FTP,DHCP,DNS,DDNS,NTP,UPNP,RTSP etc.

Connection protocol Support ONVIF 2.1(backward compatible)
Wireless Wireless standards IEEE802.11b. 802.11g. 802.11n Draft
Frequency range 2.4 GHz  to 2.4835 GHz
Wireless Security 64/128-bit WEP. WPA/WPA2. WPA-PSK/WPA2-PSK. WPS
Transmission rate 11b: 11Mbps,11g :54Mbps,11n :135Mbps
PTZ Rotation angle Horizon:0° to 355°. Vertical: 0° to 90°
Horizontal speed 1° to 40°/S
Vertical speed 1° to 20°/S
Preset N/A
Interface Power interface 1*5.5mm power interface
Ethernet 1*RJ45 & Antenna 10M/100M Adaptive Ethernet Interface
TF card Slot 1*TF card slot. up to 128G(Don’t included TF Card)
Reset button Support
General
Specification
Power supply DC 12V 2A
power Day: 3W; Night: 12W
Operating temperature -20 to +60 degree
Operating humidity 10% to 95%
Material ABS Plastic Housing ,Outdoor Use,Waterproof IP65
Installation Rack mounting
Size(W×D×H)(mm) 137x128x92mm
Weight(kg) 0.65kg



Packing List:

1*Auto Tracking WIFI PTZ IP Camera Built-in Microphone,Loud Speaker (TF Card Optional Choose)

1*DC 12V 2A Power Supply (Optional Choose)

1*CD & Manual

1*Screws Bag

2*Antenna

1*Network Cable

Additional information

Weight 0.8 kg
Dimensions 21 × 21 × 15 cm
Sensor Size

1080P 12V 2A Power, 1080P 16GB 2A Power, 1080P 32GB 2A Power, 1080P 64GB 2A Power, 1080P No Power

Origin

CN(Origin)

Ships From

China, Russian Federation, SPAIN, United States

Two Way Audio

Support Talk Back(With Speaker)

Plug Type

AU Plug, EU Plug, UK Plug, US Plug

Housing Material

ABS Plastic,Waterproof IP65

Focus

3.6mm

Power Consumption(W)

Day: 3W; Night: 12

Dimensions (L x W x D)(mm)

165*150*90mm

Audio Output

Built-in Loud Speaker

Lens (mm)

3.6mm

Power Supply(V)

12V 2A

LEDs

6Pcs White light/4Pcs IR LEDs

Special Features

Waterproof / Weatherproof

Power Supply

Normal

High Definition

2.0 Megapixels

Technology

Infrared

Minimum Illumination(Lux)

0.05 Lux /0 Lux(IR on)

Style

Dome Camera

is_customized

Yes

Sensor Brand

SONY

Wireless Protocols

802.11b/g/n, 150Mbps, 10-50m

Microphone Range 15m

Loudspeaker Range 60m

Installation

Side

Wall Bracket

Side

Supported Operating Systems

windows xp

Pan Tilt Rotation

Horizontal:355 Degree & Vertical:90 Degree

Video Compression Format

H.265

Viewing Angle

75°

Color

white

Model Number

HX-HD22M102M & HX-HD22M102M

Network Interface

RJ-45 10/100Mb Ethernet Slot

1 TF card slot

Up to 128G(Don't included TF Card)

Certification

CE

Brand Name

BOAVISION

Item Name

2.5 Inch Super Mini PTZ Dome WIFI IP Camera

Type

IP Camera

Storage

None

Supported Mobile Systems

Android

Support iPhone,Android APP

CamHipro/Camhi

Megapixels

2MP

Connectivity

IP/Network Wireless

Alarm Action

Local Alarm

IR Distance(m)

IR 30m

Fixed Lens

3.6mm Fixed Lens

Sensor

CMOS

TF Card

None

Resolution

HD 1080P
