BESDER 5MP 3MP HD 2.8mm Wide IP Camera 1080P Email Alert XMEye ONVIF P2P Motion Detection RTSP 48V POE Surveillance CCTV Outdoor

$22.11$39.03

Brand Name: BESDER
Type: ip camera
Supported Operating Systems: Windows 7
Supported Operating Systems: windows 10
Supported Operating Systems: windows 8
Supported Operating Systems: windows xp
High Definition: 1080P(Full-HD)
Lens (mm): 6mm
Lens (mm): 2.8mm
Lens (mm): 3.6mm
Style: Bullet Camera
Certification: CE
Connectivity: IP/Network Wired
Origin: CN(Origin)
Installation: Embedded
Wall Bracket: Side
Power Consumption(W): Less than 6W
Color: Black
Minimum Illumination(Lux): 0.1 Lux
Sensor: CMOS
Megapixels: 5MP
Sensor Brand: SmartSens
Special Features: Waterproof / Weatherproof
Storage: None
Alarm Action: FTP Photo
Alarm Action: Email Photo
Video Compression Format: H.264
Video Compression Format: H.265
Power Supply: Normal
TF Card: None
IR Distance(m): 15 Meters
is_customized: Yes
Power Supply(V): 12V
Model Number: 6024PB-IP20H1
Viewing Angle : 75°
Technology: Infrared
Supported Mobile Systems: Android
Supported Mobile Systems: ios
Network Interface: RJ-45 10/100Mb Ethernet Slot
Audio Output: None
Funtion: Motion detection/RTSP/FTP etc
Power supply: Not included !!!
Material: ABS Plastic
Mobile Monitoring: Supports by APP XMEye
Motion Detect: Supports multi Area
ONVIF: Yes
Power: DC 12V or 48V PoE Switch
P2P: Support
Website: xmeye.net
IR Night: 24 Pcs infrared LEDs
Special Feature: Waterproof
Style 1: IP Camera / Camera IP
Style 2: WIred Camera / Security CCTV Camera
Style 3: Outdoor Camera/ Indoor Camera

2MP 48V PoE
2MP 48V PoE
2MP DC 12V
2MP DC 12V
3MP 48V PoE
3MP 48V PoE
3MP DC 12V
3MP DC 12V
5MP 48V PoE
5MP 48V PoE
5MP DC 12V
5MP DC 12V
China
China
Russian Federation
Russian Federation
2.8mm
2.8mm
3.6mm
3.6mm
6mm
6mm
Clear

Description

New 5MP PTZ WiFi IP Camera

Pay Attention !!

Power adapter or power supply is not included in this bullet wired IP camera !!!

Main Features:

● 2MP 3MP 5MP Resolution Optional; ● H. 265 High Profile, support dual-stream, AVI format; ● With IR-CUT, Support day/night switch, up to 15m IR night vision; ● Stream 2MP: Main Stream: 1920*1080 20fps; Sub Stream :704*576 25fps 3MP: Main Stream: 2048*1536/1920*1080 18fps ;Sub Stream:704*576 25fps 5MP: Main Stream: 2592*1944/2560*1440 18fps ;Sub Stream:704*576 25fps ● Power way: DC 12V/ 48V PoE Optional; ● 24pcs Array LED, 5-25m IR distance for night vision; ● Multi-screen software and CMS ; ● Image processing: auto exposure(AE), auto white balance(AWB), auto gain control(AGC); ● Support motion detection, ONVIF 2.0; ● Support remotely access by smartphone XMEye app; ● Interface:1pcs RJ45 10M/100M self-adaptive Ethernet interface; ● DC 12V 1A-2A ( Not included ) Or 48V PoE Switch/Injector For PoE version ( Not included ); ● Working condition: -20~60 degree, humidity less than 90%(non-condensing).

Package contents:

1 * IP Camera 1 * English User Manual 1 * Rain waterproof Set 1 * Screw

Warm Tips: DC 12V and 48V PoE Version Optional : ) DC 12V Version Can Just Work With DC 12V 1A-2A Power Supply ( NOT INCLUDED ) 48V PoE Version Has PoE Module Inside Which Can Work With DC PSU 12V1A-2A & 48V PoE Switch/Injector (NOT INCLUDED )

5MP/ 3MP / 2MP Ultra HD pixels

Equipped with 5MP or3MP ultra-high-definition lens to make details display clearer

H.265 Video Compression

H.265 takes only 30% of that H.264 regarding bitrates and storage space

Motion Detection & Alert Notification

If an exception is detected, it will push information to prompt the mobile phone app and the bound mailbox, and automatically send the abnormal picture to the mobile phone.

Day And Night Vision

Built-in 24Pcs IR Cut with IR LEDs, Up to 20m(65ft) IR distance

Water& Weather Proof

Waterproof IP65, designed for indoor and outdoor. Working at temperature from -10 to 55 degree

Multiple Viewing Methods

Support mobile phones, tablet computers, and multi-platform viewing Suppory IOS / Android App Xmeye and PC software CMS .

Power Over Ethernet(PoE)

Powered via Ethernet power and transmit video signal at the same time. Please note , such Poe Camera in this link has one more Power port for DC 12V Power supply too .

P2P Remote Viewing

Whenever and wherever you are, you can connect your camera by the mobile device, watch live streams and Protect your home.

Installing & Usage

You might need one such camera at your house ,Official or garden to monitor and protect more thing .

Connection method

DC12V version

48V PoE version

FAQ :

Q:What’s the default ip address of the camera ? F: 192.168.1.10 Username : admin Password : null ( empty ) ! Q: Does the camera supports Motion Detect,FTP,Email alarm, RTSP and so on ? F: Yes ! All the IP Cameras we are selling supports these functions . 1) Please Setup the motion detection in the CMS software . 2) We suggest the Sever-U and FileZilla FTP Server to upload the video or image. 3) For the Email alarm,please use Email server which supports SMTP ( Hotmail ,Yahoo not support SMTP ,try Gmail please ) . 4) ,RTSP URL for VLC media Player : rtsp://$(IP):$(PORT)/user=$(USER)&password=$(PWD)&channel=$(Channel)&stream=$(Stream).sdp?real_stream Example : rtsp://10.6.10.25:554/user=admin&password=&channel=1&stream=0.sdp?real_stream F: What’re the ports information of the cameras ? Q : ONVIF 2.0 Port 8899 ;RTSP Port 554 ;HTTP Port 80;Media Port 34567 F:Does the camera support IE ,Chrome ,Firefox and so on ? Q: Since the plug-in problem ,for website interface IP address URL,ONLY IE supports Multi Language . Chrome,Safari just support Chinese . For cloud server XMEYE.NET ,it supports multi language Q:When I finish the steps to add the camera to the CMS list,why it notify “ Can’t find the Device “ even I can see the default ip address 192.168.1.10 in the menu . F: It is the IP Address conflict ,the default ip address is not in the same network segment as your router. Please click “Edit Device “ to change the camera’s ip address to make them in the same network segment ! For example ,if your router’s ip address is 192.168.0.1 ,then you need to change the camera’s ip address to 192.168.0.XX .

Additional information

Weight 0.4 kg
Dimensions 20 × 12 × 11 cm
Sensor Size

2MP 48V PoE, 2MP DC 12V, 3MP 48V PoE, 3MP DC 12V, 5MP 48V PoE, 5MP DC 12V

Origin

CN(Origin)

Power Consumption(W)

Less than 6W

Ships From

China, Russian Federation

Focus

2.8mm, 3.6mm, 6mm

Audio Output

None

Website

xmeye.net

Lens (mm)

3.6mm

Power Supply(V)

12V

ONVIF

Yes

IR Night

24 Pcs infrared LEDs

Special Features

Waterproof / Weatherproof

Power Supply

Normal

High Definition

1080P(Full-HD)

Style 2

WIred Camera / Security CCTV Camera

Style 1

IP Camera / Camera IP

Technology

Infrared

Style 3

Outdoor Camera/ Indoor Camera

Minimum Illumination(Lux)

0.1 Lux

Style

Bullet Camera

is_customized

Yes

Sensor Brand

SmartSens

Special Feature

Waterproof

Installation

Embedded

Wall Bracket

Side

Supported Operating Systems

windows xp

Video Compression Format

H.265

Viewing Angle

75°

Color

Black

Material

ABS Plastic

Model Number

6024PB-IP20H1

Funtion

Motion detection/RTSP/FTP etc

Network Interface

RJ-45 10/100Mb Ethernet Slot

Certification

CE

P2P

Support

Brand Name

BESDER

Mobile Monitoring

Supports by APP XMEye

Type

ip camera

Storage

None

Supported Mobile Systems

ios

Megapixels

5MP

Connectivity

IP/Network Wired

Alarm Action

Email Photo

IR Distance(m)

15 Meters

Motion Detect

Supports multi Area

Power

DC 12V or 48V PoE Switch

Sensor

CMOS

TF Card

None

Reviews

There are no reviews yet.

Be the first to review “BESDER 5MP 3MP HD 2.8mm Wide IP Camera 1080P Email Alert XMEye ONVIF P2P Motion Detection RTSP 48V POE Surveillance CCTV Outdoor”

Your email address will not be published. Required fields are marked *
